SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 3-53
3.6 Oriented spindle stop
Function
When the oriented spindle stop function is active, the spindle is always
stopped in a preselected position (e.g. position for chuck wrench).
Sequence of operations
Spindle
Select the soft key labeled "Spindle" in the extended soft key menu in
any mode.
Enter oriented stop position,
e.g.: 11.0°
Confirm your selection by pressing the "Input" key
Orient ON
Press the "Orient ON" soft key (if necessary, selectable with separate
switch on machine).
Stop spindle.
The spindle stops at the preselected position.
