cles
11
© Siemens AG, 2002. All rights reserved
11-172 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
11.1 Alarms and messages in ManualTurn cycles
11.1.1 Error handling in cycles
If an illegal status is recognized in the cycles an alarm is generated
and machining aborted.
Alarms 61000 to 62999 are generated in the cycles. The deletion
criterion for this range is NC_RESET. This aborts block preparation in
the NC. The error text that is displayed together with the alarm number
gives more detailed information about the cause of the fault.
11.1.2 Overview of cycle alarms
The error numbers are classified as follows:
6_X__
• X=0 General cycle alarms
• X=1 Deep hole drilling cycle alarms
• X=6 Turning cycle alarms
The table below lists all the errors that occur in the cycles, where they occur and
how they can be remedied.
Alarm number Alarm text Cycle Explanation, Remedy
61101 "Reference plane
incorrectly defined"
Deep hole
drilling
Either different values must be entered
for the reference plane and return plane
for incremental definition of the depth or
an absolute value must be entered for
the depth.
61107 "First drilling depth
incorrectly defined"
Deep hole
drilling
First drilling depth is not compatible with
total drilling depth.
61244 "Thread pitch change
causes undefined thread"
Thread cutting Check thread geometry.
61602 "Tool width incorrectly
defined"
Grooving in
STOCK
REMOVAL
Grooving tool is larger than program-
med groove width
61604 "Active tool violates
programmed contour"
Cutting in
STOCK
REMOVAL
Contour violation in relief cut elements
caused by the clearance angle of the
tool used, i.e. use a different tool or
check the programmed contour
61605 "Contour incorrectly
programmed"
Cutting in
STOCK
REMOVAL
Illegal relief cut element detected
