9
© Siemens AG, 2002. All rights reserved
SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 9-159
9.1.2 Simultaneous recording
Function
The results of an EasyStep machining sequence can be displayed on
the screen in real time by means of the "Simultaneous recording"
function.
Sequence of operations
Simultan-
eous rec.
You can select the "Simultaneous recording" function in the extended
soft key menu of every operating mode.
Press the "Spindle start" and "NC start" keys to start execution.
The same soft key functions are available as under "Simulation" (see
Section "Simulation"). The function "Delete screen" is also available.
Delete
screen
Select this soft key to delete the current screen contents.
9.1.3 Dry run
Function
You can simulate a programmed EasyStep machining sequence on
the screen by activating the "Dry run" function.
Explanation of soft keys
Dry run
All axis movements on the machine tool are disabled.
The "Dry run" soft key only appears if no program is active, that is, if
the program is in RESET state (press RESET key).
Dry run
feedrate
When you press the soft key "Dry run feedrate", the feed movements
are simulated at the dry run speed specified in the machine data.
Additional notes
In a dry run the machine and auxiliary functions are output by the NC
and can be suppressed by the machine manufacturer, if required.
Please follow the advice of the machine manufacturer.
