08.02 Turning with Cycles
5.2 Turnin
g
c
y
cles in CYCLE mode
5
© Siemens AG, 2002. All rights reserved
SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 5-99
X1
Drilling depth (inc) or end diameter (abs) where the final drilling depth
is.
Face end
R
Radius of hole circle
For drilling behind the turning center, you must enter a negative
parameter value.
N
Number of holes
α
αα
α0
Base rotation angle
(see peripheral end)
α
αα
α1
Advance angle
(see peripheral end)
Z0
Reference point
Z1
Final drilling depth.
For setting the parameters for the deep hole drilling cycle/thread
drilling cycle contained in the hole circle cycle, please proceed as
described in section "Drilling in the longitudinal axis (center)".
