7-142 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
Explanation of soft keys
Program
on
Selects/deselects a parts program loaded in the editor.
New
program
Creates a new EasyStep chain in the G code editor.
Editor
Calls a selected parts program in the G code editor so that it can be
edited.
Block
search
See section on "Block search"
Single
block
See Section "Single block"
Influence
You can change the machining mode for a parts program during
execution by means of the functions "Skip block" and "Program stop
M01".
Skip
block
Skip block: the block is not taken into account at program run.
M01
Program stop M01: when the function is active program execution is
stopped at those blocks in which the M function M01 is programmed.
The screen then displays "Stop: M00/M01 active". To continue
execution, press the NC Start key. If the function is not activated, the
M function M01 (from the parts program) is not taken into account.
Directory
A parts program overview is overlaid.
Program selection for execution is possible in this area (see also the
Section "Parts program management").
Press the ETC key to display the functions R parameters and G code.
R
parameters
The R parameters are displayed.
G code
Switchover to "G code": soft key is active
G code
Switchover from "G code": soft key is not active
