Siemens SINUMERIK 810D Operation & Programming Manual

12
Examples 08.02
12.1 Exam
p
le 1: External machinin
g
with
g
roove and thread
12
© Siemens AG, 2002. All rights reserved
12-186 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
Result
• Press soft key
4. Stock removal (roughing)
•
Stock
removal
and enter stock removal parameters for roughing:
T1 F: 0.2 mm/rev FR: 0.1 mm/rev S: 150 m/min
Longitudinal
External ß
Infeed depth D: 3 inc
Finishing allowance Ux: 0.4 inc Uz: 0.1 inc
Blank description: Cylinder
Allowance X
D
: 0 inc Z
D
: 2 inc
Machine relief cuts: No
Machine tool angle: Yes
Insert angle α
αα
α: 80°
Main cutting edge angle β
ββ
β: 93°
• Press the soft key
Result
5. Stock removal (finishing)
•
Stock
removal
and enter stock removal parameters for finishing:
T2 F: 0.14 mm/rev S: 220 m/min
Longitudinal
External ß
Machine relief cuts: No
Machine tool angle: Yes
