2

Operation 08.02

2.1 O

p

erator

p

anels

2

© Siemens AG, 2002. All rights reserved

2-20 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition

Slimline operator panel

OP 010S

1

A3

A4

A2

8

A2

Operator panel OP 010S

With CNC full keyboard

OP 032S

Tool

Offset

Program

Program

Manager

Alarm

5

6

7

CNC keyboard OP 032S

1 Monitor

2 Monitor keys

3 Horizontal soft key menu

4 Vertical soft key menu

5 Alpha pad

6 Correction/cursor pad with control keys

7 Numeric pad

8 USB interface
