ut
4
© Siemens AG, 2002. All rights reserved
4-70 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
Sequence of operations
Select the CONICAL mode.
a) Taper turning with specified path dimension
XZ
Select soft key labeled "XZ".
Enter traversing paths and confirm your selections by pressing the
"Input" key
e.g. X 100 abs
Z –325 inc.
b) Taper turning with specified path dimension and angle
Zα
Select desired soft key with path dimension and angle specifications
Enter traversing path and angle and confirm by pressing the "Input"
key
e.g. Z –325 abs
α 4°.
c) Positioning with linear axis (X/Z) and rotary axis (C)
XZC
Select the soft key labeled "XZC".
Enter traversing paths and confirm your selections by pressing the
"Input" key
e.g. Z 100 abs
C 20 inc.
Enter feed type (rapid traverse or mm/min) and confirm by pressing
the "Input" key
e.g. F 2 mm/min.
Initiate feed motion by pressing the Start key.
The feed motion can be interrupted at any time by means of the Stop
key. When you switch over between XZ, Xα and Zα, a value
conversion is performed if permitted by the existing values.
