Siemens SINUMERIK 840D

7
08.97 Transformations
7.4 Inclined axis: TRAANG
7
840D
NCU 572
NCU 573
810D 840Di

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA)
−
04.00 Edition
7-249
The following settings are defined in machine data:
•
The angle between a machine axis and the
inclined axis.
•
The position of the tool zero with reference to the
origin of the coordinate system declared in the
"inclined axis" function.
•
The velocity reserve available on the parallel axis
for the compensation movement.
•
The axis acceleration reserve available on the
parallel axis for the compensation movement.
Axis configuration
In order to program in the Cartesian coordinate
system, the relationship between this coordinate
system and the real machine axes (MU, MC) must
be declared in the control:
•
Names of the geometry axes
•
Assignment of the geometry axes to the channel
axes
– General case (inclined axis not active)
– Inclined axis active
•
Assignment of the channel axes to the machine
axis numbers
•
Identification of the spindles
•
Assignment of machine axis names
The procedure is the same as for the normal axis
configuration with the exception of "Inclined axis
active".
