15.1 List of instructions
15

Siemens AG 2000. All rights reserved
15-484
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
ACP Absolute dimension setting for rotary axes,
approach position in positive direction
A=ACP(...) B=ACP(...)
C=ACP(...)
s
ACOS Arccosine (trigon. function) Real
ADIS Resurfacing distance for path functions G1,
G2, G3, ...
Real,
without sign
m
ADISPOS Resurfacing distance for rapid traverse G0 Real,
without sign
m
ALF Angle lift fast Integer,
without sign
m
AMIRROR Programmable mirroring (additive mirror) AMIRROR X0 Y0 Z0
; separate block
s3
AND Logical AND
ANG Contour definition angle Real
AP Polar angle (Angle Polar) 0, ...,
±
360
°
m,s
3
APR Read/display access protection
(access protection read)
Integer,
without sign
APW Write access protection
(access protection write)
Integer,
without sign
AR Aperture angle (angle circular)
0, ..., 360
°
m,s
3
AROT Programmable rotation
(additive rotation)
Rotation
around 1st
geom. axis:
–180
o
.. 180
°
2nd geom.
axis:
–89.999
°
.. 90
°
3rd geom.
axis:
–180
°
..
180
°
AROT X... Y... Z...; separate
AROT RPL= block
s3
AS Macro definition String
ASCALE Programmable scaling (additive scale) ASCALE X... Y... Z...
; separate block
s3
ASIN Arcsine (trigon. function) Real
ASPLINE
7
Akima spline m1
ATAN2 Arctangent 2 Real
ATRANS Additive programmable offset
(additive translation)
ATRANS X... Y... Z...
; separate block
s3
AX Integer without sign Real m,s
3
AXCSWAP Switch container axis
AXCSWAP(CTn,CTn+1,...)
25
AXIS Data type: Axis name Name of file can be
added
