Siemens SINUMERIK 840D

15
12.98 Tables
15.1 List of instructions
15

Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15-485
AXNAME Converts the input string to an axis name
(get axname)
String An alarm is
generated if the
input string does
not contain a valid
axis name
AXSTRING Convert axis name to string
(get axis as string)
AXIS Name of file can
be added
B Axis Real m,s
3
B_AND Bit AND
B_NOT Bit negation
B_OR Bit OR
B_XOR Bit exclusive OR
B2
5
Tool orientation:
Euler angle
Real s
B3
5
Tool orientation:
Direction vector component
Real s
B4
5
Tool orientation for block beginning Real s
B5
5
Tool orientation for block end;
Normal vector component
Real s
BAUTO
7
Definition of first spline segment by means of following 3
points (begin not a knot)
m19
BLSYNC Processing of interrupt routine is only to start with the
next block change
BNAT
1,7
Natural transition to first spline block
(begin natural)
m19
BOOL Data type: Boolean value TRUE / FALSE or 0 / 1
BRISK
1
Brisk path acceleration m21
BRISKA Activate brisk axis acceleration for the programmed axes
BSPLINE
7
B spline m1
BTAN
7
Tangential transition to first spline block
(begin tangential)
m19
C Axis Real m,s
3
C2
5
Tool orientation: Euler angle Real s
C3
5
Tool orientation:
Direction vector component
Real s
C4
5
Tool orientation for block beginning Real s
C5
5
Tool orientation for block end;
Normal vector component
Real s
CAC Absolute approach of position
(coded position: absolute coordinate)
Coded value is
table index; table
value is
approached
