15
Tables 12.98
15.1 List of instructions
15
Siemens AG 2000. All rights reserved
15-490
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
EGOFC Switch off electronic gear continuous
(Electronic gear OFF continuous)
EGOFS Switch off electronic gear selectively
(Electronic gear OFF selective)
EGON Switch on electronic gear
(electronic gear ON)
without
synchronization
EGONSYN Switch on electronic gear
(electronic gear ON synchronized)
with
synchronization
ELSE Program branch, if IF condition not fulfilled
ENABLE Interrupt ON
ENAT
1,7
Natural curve transition to next traversing block
(end natural)
m20
ENDFOR End line of FOR counter loop
ENDIF End line of IF branch
ENDLOOP End line of endless program loop LOOP
ENDPROC End line of program with start line PROC
ENDWHILE
End line of WHILE loop
ETAN
7
Tangential curve transition to next traversing block at
beginning of spline (end tangential)
m20
EVERY Execute synchronized action if condition changes from
FALSE to TRUE
EXECTAB Execute an element from a motion table
(execute table)
EXECUTE Program execution ON Switch back to
normal program
execution from
reference point edit
mode or after
creating a
protection zone
EXP Exponent function e
x
Real
EXTERN Broadcast a subroutine with parameter passing
F Feed value
(dwell time is also programmed under F in
conjunction with G4)
0.001, ...,
99 999.999
Tool/workpiece
path velocity;
Dimension in
mm/min or
mm/revolution as a
function of G94 or
G95
F=100 G1 ...
