15
04.00 Tables
15.2 List of s
stem variables
15
ï›™
Siemens AG 2000. All rights reserved
SINUMERIK 840D/840Di/810D/FM-NC Programming Guide Advanced (PGA) – 04.00 Edition
15-517
Identifier Type Description: System variable/value range/index Part pro Sync O S
$TC_DP17
REAL $TC_DP17[t,d]
Slotting saw: Wear – Length – $TC_DP8
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP17[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP18
REAL $TC_DP18[t,d]
Wear – Reserved – $TC_DP9
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP18[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP19
REAL $TC_DP19[t,d]
Wear – Angle between face of tool and torus surface – $TC_DP10
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP19[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP20
REAL $TC_DP20[t,d]
Wear – Angle between tool longitudinal axis and upper end of torus
surface – $TC_DP11
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP20[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP21
REAL $TC_DP21[t,d]
Base – Length 1
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP21[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
$TC_DP22
REAL $TC_DP22[t,d]
Base – Length 2
With active 'Flat D number management' function, the syntax is as
follows:
$TC_DP22[d]
t: T number 1–32000
d: Cutting edge number/D number 1–32000
RW 2
