residual material
6
© Siemens AG, 2002. All rights reserved
6-126 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
6.8 Machining residual material
Function
With stock removal against the contour, residual material is
automatically detected and an updated blank contour generated. The
excess material can be removed using a suitable tool with the
"Residual material" function.
This function is a software option.
Stock removal of free contours is usually programmed as described
below:
1. Stock removal (roughing)
2. Residual material (roughing)
3. Stock removal (finishing)
Residual
material
In the basic soft key menu of CONTOUR mode, confirm the soft key
labeled "Residual material".
Explanation
A more detailed description of the parameters can be found in Section
"Stock removal against the contour".
Machining
Parallel to contour or axis (facing/longitudinal)
External/internal/face end/rear side
Machining mode
Roughing
Direction of machining
Machining can be performed from the face end to the rear end, or
from inside out towards the exterior, as well as vice versa.
D
Infeed depth
U
X
, U
Z
Finishing allowance
Relief cuts
Machine relief cuts
Tool angle
Machine tool angle
α
αα
α
Tool insert angle
β
ββ
β
Tool main cutting edge angle
