Page #57 background imageLoading...
Page #57 background image
3
08.02 Preparatory Functions for Machining
3.8 Tool
3
Ā© Siemens AG, 2002. All rights reserved
SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 3-57
3.8.2 Selecting/deselecting tool offset
Function
When the tool is selected, the control includes the programmed tool
lengths in the X and Z directions in its calculations. The values for the
tool tip position and tool nose radius are activated at the same time.
Sequence of operations
Tool offset
Select the soft key labeled "Tool offset".
Select an offset
Select
Select tool to be offset with cursor and press soft key "Select".
The activated tool is identified by the marker ">".
Deselect an offset
Deselect
Select the soft key labeled "Deselect".
This deselection causes tool number 0 to be selected. This has no
programmed offset values.
Offsets can be selected/deselected provided that no Start command is
active. The offset data are calculated in the absolute display.
This process does not involve any axis motions.
