s
7
© Siemens AG, 2002. All rights reserved
SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 7-135
7.4.3 Insert G code step
Function
G code steps and comments can be inserted into a machining
sequence.
Special
functions
G code
block
In PROGRAM mode, select soft keys "Special functions" and "G code
block".
Programming G code step
• A G code block cannot be inserted after the program end.
• It is not possible to display the G code block in the contour view.
For a detailed description of G code programming, please refer to:
/PG/, Programming Guide, Fundamentals
Comments
Comments can be inserted in the program to provide information
about the individual program steps. Comments start with a semicolon
";".
You insert the step into the machining sequence by pressing the
"Input" key and the "Accept" soft key.
7.4.4 Changing program steps
Sequence of operations
You can call the EasyStep flow chart from every mode (except for
MANUAL) via the information key.
Select the desired program step in the machining sequence with the
cursor.
Press the "Input" key.
The dialog screen form for the selected program step now appears on
the screen. The selected cycle is displayed zoomed in the program-
ming graphics.
You can now alter the parameters.
Select the soft key labeled "Accept" to update all the data in the
selected program step of the machining sequence.
