© Siemens AG, 2002. All rights reserved
SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 8-153
8.6 Rename/copy file
Sequence of operations
Precondition
The file is selected.
Copy
Rename
Select the function you require by choosing the appropriate soft key.
Enter a new file name and accept by pressing the "Input" key or "OK"
soft key.
Press soft key "Back" to abandon the function.
8.7 Read out a file to an external medium
When exporting data to an external data medium, please note the
output formats and device settings of the RS-232-C interface.
Sequence of operations
Position the cursor in the directory on the file you want to export.
Read-out
RS-232-C
Select the soft key labeled "Read-out RS-232-C".
Start transmission from data device.
Start
Select the soft key "Start".
The selected file is now exported.
The name of the file and the number of transmitted bytes are
displayed in the "Read-out RS-232-C" window.
Stop
You can interrupt the data transmission by selecting the "Stop" key.
Selecting the "Back" soft key returns you to the higher-level directory
overview. The "Read-out RS-232-C" function remains active if a
RS-232-C transmission has already been started.
All
files
When you press the soft key labeled "All files", all the files stored in
the program directory are selected for transfer.
NC start is not possible while the files are being exported.
