5
08.02 Turning with Cycles
5.3 Stock removal/
g
roovin
g
c
y
cles in STOCK REMOVAL mode
5
© Siemens AG, 2002. All rights reserved
SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 5-105
5.3.2 Grooving cycles
Function
With grooving cycles you can produce symmetrical and asymmetrical
grooves for longitudinal and face machining on any straight contour
elements. You can machine internal or external grooves.
Z
X
You can select one of three groove cycles with the soft keys in
operating mode STOCK REMOVAL.
