9
General Functions 08.02
9.2 Teach In
9
© Siemens AG, 2002. All rights reserved
9-162 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
TEACH 2 is now displayed in the status field "Teach In", i.e. the first
step in the sequence is always a comment (with the date and time).
The second step (TEACH 2) specifies the position at which Teach In
was selected.
The workpiece can now be machined step by step and in this way the
program created. After each NC start the counter in the status field is
incremented by the stored step as TEACH 3, TEACH 4, etc.
9.2.2 Deselecting "Teach In"
Open up the extended soft key menu with the "ETC" key in any
operating mode and
Teach
In
deactivate Teach In with the soft key "Teach In".
9.2.3 Continuing "Teach In"
You can append the Teach In steps to an existing EasyStep program.
Continue
teach
Press soft key "Continue teach" to call up the directory of PROGRAM
mode. Using the cursor keys, select the EasyStep program in which
the Teach In steps are to be appended to the machining sequence.
The "end of program" step in the selected program is deleted and the
first Teach In step starts with a comment block.
The counter (TEACH 1, TEACH 2, etc.) in the Teach In status field
only indicates the number of taught steps and not the total number of
program steps in the existing EasyStep program.
