Turning with Cycles 08.02
5.3 Stock removal/
g
roovin
g
c
y
cles in STOCK REMOVAL mode
5
© Siemens AG, 2002. All rights reserved
5-106 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
Sequence of operations
Precondition
Select STOCK REMOVAL mode and call the required grooving cycle
by pressing the soft key.
Simple grooving cycle
Grooving cycle with conicals, radii
and chamfers
Grooving cycle in a conical with
conicals, radii and chamfers
