08.02 Operation
2.5 O
p
eratin
g
s
y
stem
2
© Siemens AG, 2002. All rights reserved
SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 2-31
PROGRAM
The purpose of the EasyStep function is to allow users with no G-code
programming knowledge to create a complete, executable program by
chaining individual elements such as the following in a step-by-step
process:
• Straight, chamfer, circle, cycles
(e.g. thread, cutting, contour cycles)
• Special commands (e.g. tool change, auxiliary commands, dwell
times, programmed stop, tool nose radius compensation, zero
offsets and comments).

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
