Siemens SINUMERIK 840D Operation & Programming Manual

4
08.02 Turning Simple Contours
4
© Siemens AG, 2002. All rights reserved
SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 4-63
Turning Simple Contours
4.1 Turning in manual mode ........................................................................................... 4-64
4.2 Turning with path dimension input ............................................................................ 4-66
4.2.1 Turning with STRAIGHT mode ................................................................................. 4-67
4.2.2 Turning with CONICAL mode.................................................................................... 4-69
4.2.3 Turning with CIRCLE mode ...................................................................................... 4-71
4.3 Turning with the contour handwheel and JOG keys +/– ........................................... 4-75

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
