08.02 Turning with Cycles
5.2 Turnin
g
c
y
cles in CYCLE mode
5
© Siemens AG, 2002. All rights reserved
SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition 5-99
X1
Drilling depth (inc) or end diameter (abs) where the final drilling depth
is.
Face end
R
Radius of hole circle
For drilling behind the turning center, you must enter a negative
parameter value.
N
Number of holes
α
αα
α0
Base rotation angle
(see peripheral end)
α
αα
α1
Advance angle
(see peripheral end)
Z0
Reference point
Z1
Final drilling depth.
For setting the parameters for the deep hole drilling cycle/thread
drilling cycle contained in the hole circle cycle, please proceed as
described in section "Drilling in the longitudinal axis (center)".

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
