Fundamentals
Programming Manual, 10.2004 Edition, 6FC5 298-7AB00-0BP1
1-1
Fundamental Geometrical Principles
1
1.1 Description of workpiece points
1.1.1 Workpiece coordinate systems
In order for the machine or control to operate with the specified positions, these data must be
entered in a reference system that corresponds to the direction of motion of the axis slides. A
coordinate system with the axes X, Y and Z is used for this purpose.
Milling:
;
;
<
<
=
=
r
r
r
:
