Frames
6.6 Programmable scale factor (SCALE, ASCALE)
Fundamentals
6-28 Programming Manual, 10.2004 Edition, 6FC5 298-7AB00-0BP1
AROT
TRANS
ASCALE
Note
If you program an offset with ATRANS after SCALE, the offset values are also scaled.
Caution
Please take great care when using different scale factors! Example: Circular interpolations
can only be scaled using identical factors. You can, however, use different scale factors to
program distorted circles, for example.
