12.4 List of predefined subprograms
Fundamentals
Programming Manual, 10.2004 Edition, 6FC5 298-7AB00-0BP1
12-45
Predefined subprogram calls
2. Axis groupings
1st-8th
parameter
Explanation
FGROUP Channel axis
identifiers
Variable F value reference: defines the axes to which the path feed refers.
Maximum axis number: 8
The default setting for the F value reference is activated with FGROUP ( ) without
parameters.
1st-8th
parameter
2nd-9th
parameter
Explanation
SPLINEPATH INT: Spline
group (must be
1)
AXIS:
Geometry or
special axis
identifier
Definition of the spline group
Maximum number of axes: 8
BRISKA AXIS Switch on brisk axis acceleration for the programmed axes
SOFTA AXIS Switch on jerk limited axis acceleration for programmed axes
DRIVEA ### AXIS Switch on knee-shaped acceleration characteristic for programmed
axes
JERKA AXIS The acceleration behavior set in machine data
$MA_AX_JERK_ENABLE is active for the programmed axes.
# The vocabulary word is not valid for SINUMERIK 810D/NCU571.
# #The vocabulary word is not valid for SINUMERIK 810D.
### The vocabulary word is only valid for SINUMERIK FM-NC.
3. Coupled motion
Vocabulary
word/
subprogram
identifier
1st parameter 2nd
param.
3rd
param.
4th
param.
5th
param.
6th
param.
Explanation
TANG AXIS: Axis
name
Following axis
AXIS:
Leading
axis 1
AXIS:
Leading
axis 2
REAL:
Coupling
factor
CHAR:
Option:
"B":
follow-up
in basic
coordinat
e system
"W":
follow-up
in work-
piece
coord.
system
CHAR
Optimiz-
ation:
"S"
default"P
"
autom.
with
rounding
travel,
angle
tolerance
Preparatory instruction for
the definition of a tangential
follow-up: The tangent for the
follow-up is determined by
the two master axes
specified. The coupling factor
specifies the relationship
between a change in the
angle of tangent and the
following axis. It is usually 1.
Optimization: See PGA
TANGON AXIS: Axis
name
Following axis
REAL:
Offset
Angle
REAL:
Round
-ing
travel
REAL:
Angle
toleranc
e
Tangential follow-up mode
ON
par. 3, 4 with TANG Par. 6 =
"P"
