Siemens SIPART PS2 series User Manual

Parameter Function Parameter values Unit
12.SFCT Setpoint function
Linear Lin
Equal percentage 1 : 25 1 - 25
1 : 33 1 - 33
1 : 50 1 - 50
Inverse equal percent‐
age
25 : 1 n1 - 25
33 : 1 n1 - 33
50 : 1 n1 - 50
Freely adjustable FrEE
13.SL0 ...
33.SL20
1)
Setpoint turning point
13.SL0 At 0 % 0.0 ... 100.0 %
14.SL1 .... 5 % ...
32.SL19 95 %
33.SL20 100 %
34.DEBA Deadband of closed-loop controller Auto / 0.1 ... 10.0 %
35.YA Start of manipulated variable limit 0.0 ... 100.0 %
36.YE End of manipulated variable limit 0.0 ... 100.0 %
37.YNRM Standardization of manipulated variable
To mechanical travel MPOS
To flow FLoW
38.YDIR Direction of manipulated variable for display and position feedback
Rising riSE
Falling FALL
39.YCLS Tight closing/fast closing with manipulated variable
None no
Tight closing Up uP
Tight closing Down do
Tight closing Up and Down uP do
Fast closing Up Fu
Fast closing Down Fd
Fast closing Up and Down Fu Fd
Tight closing Up and fast clos‐
ing Down
uP Fd
Fast closing Up and tight clos‐
ing Down
Fu do
40.YCDO Value for fast closing/tight closing
Down
0.0 ... 0.5 ... 100.0 %
41.YCUP Value for fast closing/tight closing Up 0.0 ... 99.5 ... 100.0 %
Parameter assignment
8.3 Tabular overview of the parameters
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 137

Siemens SIPART PS2 series Specifications

General

Supply Pressure	1.4 to 7 bar (20 to 100 psi)
Enclosure Rating	IP66/NEMA 4X
Type	Electropneumatic
Input Signal	4-20 mA
Stroke Range	3 to 200 mm
Rotary Range	30 to 100°
Mounting	Linear or rotary actuators
Certifications	ATEX, IECEx, FM, CSA
