6. Insert the booster ⑭ via the threaded bolts ③.
7. Fasten the booster ⑭ with the lock washers ④ and nuts ⑤. When tightening, make sure
that the shaft ① can be turned easily.
Booster
E.2 Mounting a booster
SIPART PS2 with 4 to 20 mA/HART
Operating Instructions, 11/2019, A5E00074631-AE 303
