Siemens SIPROTEC 4 7SD80 User Manual

Addr. Parameter Function C Setting Options Default Setting Comments
3722 59G-1-3V0PICKUP 27/59 O/U Volt. 1.0 .. 220.0 V; ∞ 30.0 V 59G-1 Pickup 3V0 (zero
seq.)
3723 59G-1-3V0 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
2.00 sec 59G-1 Time Delay
3724 59G-2-3V0PICKUP 27/59 O/U Volt. 1.0 .. 220.0 V; ∞ 50.0 V 59G-2 Pickup 3V0 (zero
seq.)
3725 59G-2-3V0 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
1.00 sec 59G-2 Time Delay
3728A 59G-3Vo Stabil. 27/59 O/U Volt. ON
OFF
ON 59G: Stabilization 3Vo-
Measurement
3729A 59G RESET 27/59 O/U Volt. 0.30 .. 0.99 0.95 Reset ratio
3731 59-V1 Mode 27/59 O/U Volt. OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode V1 over-
voltage prot.
3732 59-1-V1 PICKUP 27/59 O/U Volt. 2.0 .. 220.0 V; ∞ 150.0 V 59-1 Pickup Overvoltage
(pos. seq.)
3733 59-1-V1 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
2.00 sec 59-1 Time Delay
3734 59-2-V1 PICKUP 27/59 O/U Volt. 2.0 .. 220.0 V; ∞ 175.0 V 59-2 Pickup Overvoltage
(pos. seq.)
3735 59-2-V1 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
1.00 sec 59-2 Time Delay
3739A 59-V1 RESET 27/59 O/U Volt. 0.30 .. 0.99 0.98 Reset ratio
3741 59-V2 Mode 27/59 O/U Volt. OFF
Alarm Only
ON
V>Alarm V>>Trip
OFF Operating mode V2 over-
voltage prot.
3742 59-1-V2 PICKUP 27/59 O/U Volt. 2.0 .. 220.0 V; ∞ 30.0 V 59-1 Pickup Overvoltage
(neg. seq.)
3743 59-1-V2 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
2.00 sec 59-1 Time Delay
3744 59-2-V2 PICKUP 27/59 O/U Volt. 2.0 .. 220.0 V; ∞ 50.0 V 59-2 Pickup Overvoltage
(neg. seq.)
3745 59-2-V2 DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
1.00 sec 59-2 Time Delay
3749A 59-V2 RESET 27/59 O/U Volt. 0.30 .. 0.99 0.98 Reset ratio
3751 27-Vph-g Mode 27/59 O/U Volt. OFF
Alarm Only
ON
V<Alarm V<<Trip
OFF Operating mode Vph-g
undervoltage prot.
3752 27-1-Vph PICKUP 27/59 O/U Volt. 1.0 .. 100.0 V; 0 30.0 V 27-1 Pickup Undervoltage
(phase-neutral)
3753 27-1-Vph DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
2.00 sec 27-1 Time Delay
3754 27-2-Vph PICKUP 27/59 O/U Volt. 1.0 .. 100.0 V; 0 10.0 V 27-2 Pickup Undervoltage
(phase-neutral)
3755 27-2-Vph DELAY 27/59 O/U Volt. 0.00 .. 100.00 sec;
∞
1.00 sec 27-2 Time Delay
Functions, Settings, Information
F.2 Settings
348 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
