No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
1511 49 Overload Protection is
OFF (49 O / L OFF)
49 Th.Over-
load
OUT O
N
OF
F
* * LED BO 16
7
11 1 Yes
1512 49 Overload Protection is
BLOCKED (49 O/L BLOCK)
49 Th.Over-
load
OUT O
N
OF
F
ON
OFF
* LED BO 16
7
12 1 Yes
1513 49 Overload Protection is
ACTIVE (49 O/L ACTIVE)
49 Th.Over-
load
OUT O
N
OF
F
* * LED BO 16
7
13 1 Yes
1515 49 Overload Current
Alarm (I alarm) (49 O/L I
Alarm)
49 Th.Over-
load
OUT O
N
OF
F
* * LED BO 16
7
15 1 Yes
1516 49 Overload Alarm! Near
Thermal Trip (49 O/L Θ
Alarm)
49 Th.Over-
load
OUT O
N
OF
F
* * LED BO 16
7
16 1 Yes
1517 49 Winding Overload (49
Winding O/L)
49 Th.Over-
load
OUT O
N
OF
F
* * LED BO 16
7
17 1 Yes
1521 49 Thermal Overload TRIP
(49 Th O/L TRIP)
49 Th.Over-
load
OUT * ON * LED BO 16
7
21 2 Yes
2054 Emergency mode (Emer.
mode)
Device,
General
OUT O
N
OF
F
ON
OFF
* LED BO 19
2
37 1 Yes
2701 >79 ON (>79 ON) 79 Auto
Recl.
SP * * * LED BI BO 40 1 1 Yes
2702 >79 OFF (>79 OFF) 79 Auto
Recl.
SP * * * LED BI BO 40 2 1 Yes
2703 >BLOCK 79 (>BLOCK 79) 79 Auto
Recl.
SP O
N
OF
F
* * LED BI BO 40 3 1 Yes
2711 >79 External start of
internal A/R (>79 Start)
79 Auto
Recl.
SP * ON * LED BI BO 40 11 2 Yes
2716 >79: External 3pole trip
for AR start (>79 TRIP 3p)
79 Auto
Recl.
SP * ON * LED BI BO 40 16 2 Yes
2727 >79: Remote Close signal
(>79 RemoteClose)
79 Auto
Recl.
SP * ON * LED BI BO 40 22 2 Yes
Functions, Settings, Information
F.3 Information List
368 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
