No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
2738 >79: Block 3pole AR-cycle
(>BLOCK 3pole AR)
79 Auto
Recl.
SP O
N
OF
F
* * LED BI BO 40 33 1 Yes
2739 >79: Block 1phase-fault
AR-cycle (>BLK 1phase
AR)
79 Auto
Recl.
SP O
N
OF
F
* * LED BI BO 40 34 1 Yes
2740 >79: Block 2phase-fault
AR-cycle (>BLK 2phase
AR)
79 Auto
Recl.
SP O
N
OF
F
* * LED BI BO 40 35 1 Yes
2741 >79: Block 3phase-fault
AR-cycle (>BLK 3phase
AR)
79 Auto
Recl.
SP O
N
OF
F
* * LED BI BO 40 36 1 Yes
2742 >79: Block 1st AR-cycle
(>BLK 1.AR-cycle)
79 Auto
Recl.
SP O
N
OF
F
* * LED BI BO 40 37 1 Yes
2743 >79: Block 2nd AR-cycle
(>BLK 2.AR-cycle)
79 Auto
Recl.
SP O
N
OF
F
* * LED BI BO 40 38 1 Yes
2746 >79: External Trip for AR
start (>Trip for AR)
79 Auto
Recl.
SP * ON * LED BI BO 40 41 2 Yes
2752 >79: External pickup
3phase for AR start
(>Pickup 3ph AR)
79 Auto
Recl.
SP * ON * LED BI BO 40 47 2 Yes
2781 79: Auto recloser is
switched OFF (79 OFF)
79 Auto
Recl.
OUT O
N
OF
F
* * LED BO 40 81 1 Yes
2782 79: Auto recloser is
switched ON (79 ON)
79 Auto
Recl.
IntS
P
* * * LED BO 19
2
16 1 Yes
2783 79: Auto recloser is
blocked (79 is blocked)
79 Auto
Recl.
OUT O
N
OF
F
* * LED BO 40 83 1 Yes
2784 79: Auto recloser is not
ready (79 not ready)
79 Auto
Recl.
OUT * ON * LED BO 19
2
13
0
1 Yes
2787 79: Circuit breaker 1 not
ready (CB not ready)
79 Auto
Recl.
OUT * * * LED BO 40 87 1 Yes
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SD80, Manual 369
E50417-G1100-C474-A2, Edition 02.2018
