No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
7132 >BLOCK 50N-3 (>BLOCK
50N-3)
Back-Up O/C SP O
N
OF
F
* * LED BI BO 64 32 1 Yes
7152 50(N)/51(N) Backup O/C
is BLOCKED (5X-B BLOCK)
Back-Up O/C OUT O
N
OF
F
ON
OFF
* LED BO 64 52 1 Yes
7153 50(N)/51(N) Backup O/C
is ACTIVE (5X-B ACTIVE)
Back-Up O/C OUT * * * LED BO 64 53 1 Yes
7154 Backup O/C stage 50(N)-
B2 is sw. OFF (50(N)-B2
OFF)
Back-Up O/C OUT * * * LED BO
7155 Backup O/C stage 50(N)-
B1 is sw. OFF (50(N)-B1
OFF)
Back-Up O/C OUT * * * LED BO
7156 Backup O/C stage 50(N)-3
is sw. OFF (50(N)-3 OFF)
Back-Up O/C OUT * * * LED BO
7157 Backup O/C stage 51(N)-B
is sw. OFF (51(N)-B OFF)
Back-Up O/C OUT * * * LED BO
7161 50(N)/51(N) Backup O/C
PICKED UP (5X-B PICKUP)
Back-Up O/C OUT * OFF m LED BO 64 61 2 Yes
7162 50(N)/51(N) Backup O/C
PICKUP Phase A (5X-B
Pickup ØA)
Back-Up O/C OUT * ON * LED BO 64 62 2 Yes
7163 50(N)/51(N) Backup O/C
PICKUP Phase B (5X-B
Pickup ØB)
Back-Up O/C OUT * ON * LED BO 64 63 2 Yes
7164 50(N)/51(N) Backup O/C
PICKUP Phase C (5X-B
Pickup ØC)
Back-Up O/C OUT * ON * LED BO 64 64 2 Yes
7165 50(N)/51(N) Backup O/C
PICKUP GROUND (5X-B
Pickup Gnd)
Back-Up O/C OUT * ON * LED BO 64 65 2 Yes
7191 50(N)-B1 Pickup (50(N)-
B1 PICKUP)
Back-Up O/C OUT * ON m LED BO 64 91 2 Yes
7192 50(N)-B2 Pickup (50(N)-
B2 PICKUP)
Back-Up O/C OUT * ON m LED BO 64 92 2 Yes
7193 51(N)-B Pickup (51(N)-B
PICKUP)
Back-Up O/C OUT * ON m LED BO 64 93 2 Yes
7201 50-3 Pickup (50-3
PICKUP)
Back-Up O/C OUT * ON
OFF
m LED BO 64 10
1
2 Yes
Functions, Settings, Information
F.3 Information List
380 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
