No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
7211 50(N)/51(N)-B General
TRIP command (5X-B
TRIP)
Back-Up O/C OUT * * * LED BO 64 11
1
2 No
7221 50(N)-B1 TRIP (50(N)-B1
TRIP)
Back-Up O/C OUT * ON * LED BO 64 12
1
2 No
7222 50(N)-B2 TRIP (50(N)-B2
TRIP)
Back-Up O/C OUT * ON * LED BO 64 12
2
2 No
7223 51(N)-B TRIP (51(N)-B
TRIP)
Back-Up O/C OUT * ON * LED BO 64 12
3
2 No
7235 50-3 TRIP (50-3 TRIP) Back-Up O/C OUT * ON * LED BO 64 13
5
2 No
7250 67(N)-B1 Pickup (67(N)-
B1 PICKUP)
Back-Up O/C OUT * On * LED BO
7251 67(N)-B2 Pickup (67(N)-
B2 PICKUP)
Back-Up O/C OUT * On * LED BO
7252 67(N)-TOC Pickup (67(N)-
TOC PICK.)
Back-Up O/C OUT * On * LED BO
7253 67(N) General TRIP
command (67(N) TRIP)
Back-Up O/C OUT * On * LED BO
7254 67(N)-B1 TRIP (67(N)-B1
TRIP)
Back-Up O/C OUT * On * LED BO
7255 67(N)-B2 TRIP (67(N)-B2
TRIP)
Back-Up O/C OUT * On * LED BO
7256 67(N)-TOC TRIP (67(N)-
TOC TRIP)
Back-Up O/C OUT * On * LED BO
7257 67 Phase A forward (67
forward ØA)
Back-Up O/C OUT * On * LED BO
7258 67 Phase B forward (67
forward ØB)
Back-Up O/C OUT * On * LED BO
7259 67 Phase C forward (67
forward ØC)
Back-Up O/C OUT * On * LED BO
7260 67N Gnd forward (67N
forward GND)
Back-Up O/C OUT * On * LED BO
7261 67 Phase A reverse (67
reverse ØA)
Back-Up O/C OUT * On * LED BO
7262 67 Phase B reverse (67
reverse ØB)
Back-Up O/C OUT * On * LED BO
7263 67 Phase C reverse (67
reverse ØC)
Back-Up O/C OUT * On * LED BO
7264 67N Gnd forward (67N
reverse GND)
Back-Up O/C OUT * On * LED BO
7265 67(N) forward (67(N)
forward)
Back-Up O/C OUT * On * LED BO
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SD80, Manual 381
E50417-G1100-C474-A2, Edition 02.2018
