No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
10205 >BLOCK 59-V2 Overvolt.
(negative seq.) (>59-V2
BLOCK)
27/59 O/U
Volt.
SP * * * LED BI BO
10206 >BLOCK 27-Vphg Under-
volt. (phase-ground)
(>27-Vphg BLOCK)
27/59 O/U
Volt.
SP * * * LED BI BO
10207 >BLOCK 27-Vphph Under-
volt (phase-phase) (>27-
Vphph BLOCK)
27/59 O/U
Volt.
SP * * * LED BI BO
10208 >BLOCK 27-V1 Undervolt
(positive seq.) (>27-V1
BLOCK)
27/59 O/U
Volt.
SP * * * LED BI BO
10215 59-Vphg Overvolt. is
switched OFF (59-Vphg
OFF)
27/59 O/U
Volt.
OUT O
N
OF
F
* * LED BO 73 15 1 Yes
10216 59-Vphg Overvolt. is
BLOCKED (59-Vphg BLK)
27/59 O/U
Volt.
OUT O
N
OF
F
ON
OFF
* LED BO 73 16 1 Yes
10217 59-Vphph Overvolt. is
switched OFF (59-Vphph
OFF)
27/59 O/U
Volt.
OUT O
N
OF
F
* * LED BO 73 17 1 Yes
10218 59-Vphph Overvolt. is
BLOCKED (59-Vphph BLK)
27/59 O/U
Volt.
OUT O
N
OF
F
ON
OFF
* LED BO 73 18 1 Yes
10219 59-3V0 Overvolt. is
switched OFF (59-3V0
OFF)
27/59 O/U
Volt.
OUT O
N
OF
F
* * LED BO 73 19 1 Yes
10220 59-3V0 Overvolt. is
BLOCKED (59-3V0 BLK)
27/59 O/U
Volt.
OUT O
N
OF
F
ON
OFF
* LED BO 73 20 1 Yes
10221 59-V1 Overvolt. is
switched OFF (59-V1
OFF)
27/59 O/U
Volt.
OUT O
N
OF
F
* * LED BO 73 21 1 Yes
10222 59-V1 Overvolt. is
BLOCKED (59-V1 BLK)
27/59 O/U
Volt.
OUT O
N
OF
F
ON
OFF
* LED BO 73 22 1 Yes
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SD80, Manual 383
E50417-G1100-C474-A2, Edition 02.2018
