No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
10266 59-2-Vphph Pickup A-B
(59-2-Vpp PU AB)
27/59 O/U
Volt.
OUT * * * LED BO 73 14
2
2 Yes
10267 59-2-Vphph Pickup B-C
(59-2-Vpp PU BC)
27/59 O/U
Volt.
OUT * * * LED BO 73 14
3
2 Yes
10268 59-2-Vphph Pickup C-A
(59-2-Vpp PU CA)
27/59 O/U
Volt.
OUT * * * LED BO 73 14
4
2 Yes
10270 59-1-3V0 Pickup
(59-1-3V0 Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 70 2 Yes
10271 59-2-3V0 Pickup
(59-2-3V0 Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 71 2 Yes
10272 59-1-3V0 TimeOut
(59-1-3V0TimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10273 59-2-3V0 TimeOut
(59-2-3V0TimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10274 59-3V0 TRIP command
(59-3V0 TRIP)
27/59 O/U
Volt.
OUT * ON * LED BO 73 74 2 Yes
10280 59-1-V1 Pickup (59-1-V1
Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 80 2 Yes
10281 59-2-V1 Pickup (59-2-V1
Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 81 2 Yes
10282 59-1-V1 TimeOut (59-1-
V1TimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10283 59-2-V1 TimeOut (59-2-
V1TimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10284 59-V1 TRIP command (59-
V1 TRIP)
27/59 O/U
Volt.
OUT * ON * LED BO 73 84 2 Yes
10290 59-1-V2 Pickup (59-1-V2
Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 90 2 Yes
10291 59-2-V2 Pickup (59-2-V2
Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 91 2 Yes
10292 59-1-V2 TimeOut (59-1-
V2TimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10293 59-2-V2 TimeOut (59-2-
V2TimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10294 59-V2 TRIP command (59-
V2 TRIP)
27/59 O/U
Volt.
OUT * ON * LED BO 73 94 2 Yes
10300 27-1-V1 Pickup (27-1-V1
Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 10
0
2 Yes
10301 27-2-V1 Pickup (27-2-V1
Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 10
1
2 Yes
10302 27-1-V1TimeOut (27-1-
V1TimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
Functions, Settings, Information
F.3 Information List
386 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
