No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
10303 27-2-V1TimeOut (27-2-
V1TimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10304 27-V1 TRIP command (27-
V1 TRIP)
27/59 O/U
Volt.
OUT * ON * LED BO 73 10
4
2 Yes
10310 27-1-Vphg Pickup (27-1-
Vpg Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 11
0
2 Yes
10311 27-2-Vphg Pickup (27-2-
Vpg Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 11
1
2 Yes
10312 27-Vphg Pickup A (27-
Vpg PU A)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 11
2
2 Yes
10313 27-Vphg Pickup B (27-Vpg
PU B)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 11
3
2 Yes
10314 27-Vphg Pickup C (27-
Vpg PU C)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 11
4
2 Yes
10315 27-1-Vphg TimeOut
(27-1-VpgTimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10316 27-2-Vphg TimeOut
(27-2-VpgTimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10317 27-Vphg TRIP command
(27-Vpg TRIP)
27/59 O/U
Volt.
OUT * ON * LED BO 73 11
7
2 Yes
10318 27-1-Vphg Pickup A
(27-1-Vpg PU A)
27/59 O/U
Volt.
OUT * * * LED BO 73 14
5
2 Yes
10319 27-1-Vphg Pickup B
(27-1-Vpg PU B)
27/59 O/U
Volt.
OUT * * * LED BO 73 14
6
2 Yes
10320 27-1-Vphg Pickup C
(27-1-Vpg PU C)
27/59 O/U
Volt.
OUT * * * LED BO 73 14
7
2 Yes
10321 27-2-Vphg Pickup A
(27-2-Vpg PU A)
27/59 O/U
Volt.
OUT * * * LED BO 73 14
8
2 Yes
10322 27-2-Vphg Pickup B
(27-2-Vpg PU B)
27/59 O/U
Volt.
OUT * * * LED BO 73 14
9
2 Yes
10323 27-2-Vphg Pickup C
(27-2-Vpg PU C)
27/59 O/U
Volt.
OUT * * * LED BO 73 15
0
2 Yes
10325 27-1-Vphph Pickup (27-1-
Vpp Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 12
5
2 Yes
10326 27-2-Vphph Pickup (27-2-
Vpp Pickup)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 12
6
2 Yes
10327 27-Vphph Pickup A-B (27-
Vpp PU AB)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 12
7
2 Yes
10328 27-Vphph Pickup B-C (27-
Vpp PU BC)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 12
8
2 Yes
10329 27-Vphph Pickup C-A (27-
Vpp PU CA)
27/59 O/U
Volt.
OUT * ON
OFF
* LED BO 73 12
9
2 Yes
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SD80, Manual 387
E50417-G1100-C474-A2, Edition 02.2018
