No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
10330 27-1-Vphph TimeOut
(27-1-VppTimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10331 27-2-Vphph TimeOut
(27-2-VppTimeOut)
27/59 O/U
Volt.
OUT * * * LED BO
10332 27-Vphph TRIP command
(27-Vpp TRIP)
27/59 O/U
Volt.
OUT * ON * LED BO 73 13
2
2 Yes
10333 27-1-Vphph Pickup A-B
(27-1-Vpp PU AB)
27/59 O/U
Volt.
OUT * * * LED BO 73 15
1
2 Yes
10334 27-1-Vphph Pickup B-C
(27-1-Vpp PU BC)
27/59 O/U
Volt.
OUT * * * LED BO 73 15
2
2 Yes
10335 27-1-Vphph Pickup C-A
(27-1-Vpp PU CA)
27/59 O/U
Volt.
OUT * * * LED BO 73 15
3
2 Yes
10336 27-2-Vphph Pickup A-B
(27-2-Vpp PU AB)
27/59 O/U
Volt.
OUT * * * LED BO 73 15
4
2 Yes
10337 27-2-Vphph Pickup B-C
(27-2-Vpp PU BC)
27/59 O/U
Volt.
OUT * * * LED BO 73 15
5
2 Yes
10338 27-2-Vphph Pickup C-A
(27-2-Vpp PU CA)
27/59 O/U
Volt.
OUT * * * LED BO 73 15
6
2 Yes
17525 85 DT: Received 3pole
(85 DT rec.3pole)
85 DT Inter-
trip
OUT On
Of
f
* * LED BO
17526 85 DT: Sending 3pole (85
DT sen.3pole)
85 DT Inter-
trip
OUT O
N
OF
F
* * LED BO
17530 67(N) Backup O/C is
BLOCKED (67(N) BLOCK)
Back-Up O/C OUT * ON * LED BO 64 14
8
2 No
17531 67(N) Backup O/C is
ACTIVE (67(N) ACTIVE)
Back-Up O/C OUT * ON * LED BO 64 14
9
2 No
17532 Backup O/C stage 67(N)-
B2 is sw. OFF (67(N)-B2
OFF)
Back-Up O/C OUT * ON * LED BO
17533 Backup O/C stage 67(N)-
B1 is sw. OFF (67(N)-B1
OFF)
Back-Up O/C OUT * ON * LED BO
17534 Backup O/C stage 67(N)-
TOC is sw. OFF (67(N)-
TOC OFF)
Back-Up O/C OUT * ON * LED BO
17535 67(N) Backup O/C PICKED
UP (67(N) PICKUP)
Back-Up O/C OUT * On * LED BO
17536 67 Backup O/C PICKUP
Phase A (67 Pickup ØA)
Back-Up O/C OUT * On * LED BO
