No. Description Function Typ
e of
Info
rma
tion
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
information number
Data Unit
General Interrogation
17537 67 Backup O/C PICKUP
Phase B (67 Pickup ØB)
Back-Up O/C OUT * On * LED BO
17538 67 Backup O/C PICKUP
Phase C (67 Pickup ØC)
Back-Up O/C OUT * On * LED BO
17539 67N Backup O/C PICKUP
GROUND (67N Pickup
Gnd)
Back-Up O/C OUT * On * LED BO
30053 Fault recording is running
(Fault rec. run.)
Osc. Fault
Rec.
OUT * * * LED BO
31000 Q0 operationcounter=
(Q0 OpCnt=)
Control
Device
VI
31001 Q1 operationcounter=
(Q1 OpCnt=)
Control
Device
VI
31002 Q2 operationcounter=
(Q2 OpCnt=)
Control
Device
VI
31008 Q8 operationcounter=
(Q8 OpCnt=)
Control
Device
VI
31009 Q9 operationcounter=
(Q9 OpCnt=)
Control
Device
VI
32100 >87L Protection blocking
signal (>87L block)
87 Diff.
Prot.
SP On
Of
f
* * LED BI BO
32102 87L Protection is active
(87L active)
87 Diff.
Prot.
OUT On * * LED BO 92 13
3
1 Yes
32103 87L Fault detection A
(87L Fault A)
87 Diff.
Prot.
OUT * On
Off
m LED BO 92 13
4
2 Yes
32104 87L Fault detection B
(87L Fault B)
87 Diff.
Prot.
OUT * On
Off
m LED BO 92 13
5
2 Yes
32105 87L Fault detection C
(87L Fault C)
87 Diff.
Prot.
OUT * On
Off
m LED BO 92 13
6
2 Yes
32107 87L Protection is blocked
(87L is blocked)
87 Diff.
Prot.
OUT On * * LED BO 92 13
2
1 Yes
32108 87L Protection is
switched off (87L is OFF)
87 Diff.
Prot.
OUT On * * LED BO 92 13
1
1 Yes
32109 87L A released (87L allow
A)
87 Diff.
Prot.
OUT * * * LED BO
32110 87L B released (87L allow
B)
87 Diff.
Prot.
OUT * * * LED BO
32111 87L C released (87L allow
C)
87 Diff.
Prot.
OUT * * * LED BO
32112 87 CT primary ratio is too
high (87 CTRatioAlarm)
87 Diff.
Prot.
OUT On
Of
f
* * LED BO
Functions, Settings, Information
F.3 Information List
SIPROTEC 4, 7SD80, Manual 389
E50417-G1100-C474-A2, Edition 02.2018
