Siemens SIPROTEC 4 7SD80 User Manual

No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
856 Ic Max (Ic Max=) Min/Max meter - - - - - CFC CD DD
857 I1 (positive sequence) Minimum
(I1 Min=)
Min/Max meter - - - - - CFC CD DD
858 I1 (positive sequence) Maximum
(I1 Max=)
Min/Max meter - - - - - CFC CD DD
859 Va-n Min (Va-nMin=) Min/Max meter - - - - - CFC CD DD
860 Va-n Max (Va-nMax=) Min/Max meter - - - - - CFC CD DD
861 Vb-n Min (Vb-nMin=) Min/Max meter - - - - - CFC CD DD
862 Vb-n Max (Vb-nMax=) Min/Max meter - - - - - CFC CD DD
863 Vc-n Min (Vc-nMin=) Min/Max meter - - - - - CFC CD DD
864 Vc-n Max (Vc-nMax=) Min/Max meter - - - - - CFC CD DD
865 Va-b Min (Va-bMin=) Min/Max meter - - - - - CFC CD DD
867 Va-b Max (Va-bMax=) Min/Max meter - - - - - CFC CD DD
868 Vb-c Min (Vb-cMin=) Min/Max meter - - - - - CFC CD DD
869 Vb-c Max (Vb-cMax=) Min/Max meter - - - - - CFC CD DD
870 Vc-a Min (Vc-aMin=) Min/Max meter - - - - - CFC CD DD
871 Vc-a Max (Vc-aMax=) Min/Max meter - - - - - CFC CD DD
874 V1 (positive sequence) Voltage
Minimum (V1 Min =)
Min/Max meter - - - - - CFC CD DD
875 V1 (positive sequence) Voltage
Maximum (V1 Max =)
Min/Max meter - - - - - CFC CD DD
880 Apparent Power Minimum
(Smin=)
Min/Max meter - - - - - CFC CD DD
881 Apparent Power Maximum
(Smax=)
Min/Max meter - - - - - CFC CD DD
882 Frequency Minimum (fmin=) Min/Max meter - - - - - CFC CD DD
883 Frequency Maximum (fmax=) Min/Max meter - - - - - CFC CD DD
888 Pulsed Energy Wp (active)
(Wp(puls))
Energy 133 55 No 205 - CFC CD DD
889 Pulsed Energy Wq (reactive)
(Wq(puls))
Energy 133 56 No 205 - CFC CD DD
924 Wp Forward (Wp+=) Energy 133 51 No 205 - CFC CD DD
925 Wq Forward (Wq+=) Energy 133 52 No 205 - CFC CD DD
928 Wp Reverse (Wp-=) Energy 133 53 No 205 - CFC CD DD
929 Wq Reverse (Wq-=) Energy 133 54 No 205 - CFC CD DD
963 I A demand (Ia dmd=) Demand meter - - - - - CFC CD DD
964 I B demand (Ib dmd=) Demand meter - - - - - CFC CD DD
965 I C demand (Ic dmd=) Demand meter - - - - - CFC CD DD
1040 Active Power Minimum Forward
(Pmin Forw=)
Min/Max meter - - - - - CFC CD DD
Functions, Settings, Information
F.5 Measured Values
SIPROTEC 4, 7SD80, Manual 395
E50417-G1100-C474-A2, Edition 02.2018
