No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
7784 I B (% of Operational nominal
current) (I B_opN=)
Measure Slave - - - - - CFC CD DD
7785 Angle I B_remote <-> I B_local (ΦI
B=)
Measure Slave - - - - - CFC CD DD
7786 I C (% of Operational nominal
current) (I C_opN=)
Measure Slave - - - - - CFC CD DD
7787 Angle I C_remote <-> I C_local (ΦI
C=)
Measure Slave - - - - - CFC CD DD
7789 V A (% of Operational nominal
voltage) (V A_opN=)
Measure Slave - - - - - CFC CD DD
7790 Angle V A_remote <-> V A_local
(ΦV A=)
Measure Slave - - - - - CFC CD DD
7791 V B (% of Operational nominal
voltage) (V B_opN=)
Measure Slave - - - - - CFC CD DD
7792 Angle V B_rem <-> V B_local (ΦV
B=)
Measure Slave - - - - - CFC CD DD
7793 V C (% of Operational nominal
voltage) (V C_opN=)
Measure Slave - - - - - CFC CD DD
7794 Angle V C_remote <-> V C_local
(ΦV C=)
Measure Slave - - - - - CFC CD DD
10102 Min. Zero Sequence Voltage 3V0
(3V0min =)
Min/Max meter - - - - - CFC CD DD
10103 Max. Zero Sequence Voltage 3V0
(3V0max =)
Min/Max meter - - - - - CFC CD DD
32204 Output power of the FO-Interface
= (OutputPower FO=)
Measure PDI - - - - - CFC CD DD
32205 Input power of the FO-Interface =
(Input Power FO=)
Measure PDI - - - - - CFC CD DD
32206 Budget of the FO-Interface =
(Budget FO =)
Measure PDI - - - - - CFC CD DD
32208 Attenuation of the Cu-Interface =
(AttenuationCu =)
Measure PDI - - - - - CFC CD DD
32209 Signal-to-noise ratio Cu-Interface
= (StN Ratio Cu=)
Measure PDI - - - - - CFC CD DD
32210 Send telegrams in the last
second= (Send Tel.sec=)
Measure PDI - - - - - CFC CD DD
32211 Good received telegrams in the
last sec= (Good Rec.sec=)
Measure PDI - - - - - CFC CD DD
32212 Bad received telegrams in the last
sec= (Bad Rec.sec =)
Measure PDI - - - - - CFC CD DD
32213 Send telegrams in the last
minute= (Send Tel.min=)
Measure PDI - - - - - CFC CD DD
32214 Good received telegrams in the
last min= (Good Rec.min=)
Measure PDI - - - - - CFC CD DD
Functions, Settings, Information
F.5 Measured Values
398 SIPROTEC 4, 7SD80, Manual
E50417-G1100-C474-A2, Edition 02.2018
