Siemens SIPROTEC 4 7SD80

No. Description Function IEC 60870-5-103 Configurable in
Matrix
Type
information number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
7752 Prot. Interf. Cu: Transmission
delay (PI Cu TD)
Measure PDI 134 122 No 9 3 CFC CD DD
7753 Prot. Interf. FO: Availability per
min. (FO A/m)
Measure PDI - - - - - CFC CD DD
7754 Prot. Interf. FO: Availability per
hour (FO A/h)
Measure PDI 134 122 No 9 2 CFC CD DD
134 121 No 9 1
7755 Prot. Interf. Cu: Availability per
min. (Cu A/m)
Measure PDI - - - - - CFC CD DD
7756 Prot. Interf. Cu: Availability per
hour (Cu A/h)
Measure PDI 134 122 No 9 4 CFC CD DD
134 121 No 9 2
7761 Relay ID of 1st. relay (Relay ID) Measure
Master
- - - - - CFC CD DD
7762 I A (% of Operational nominal
current) (I A_opN=)
Measure
Master
- - - - - CFC CD DD
7763 Angle I A_remote <-> I A_local (ΦI
A=)
Measure
Master
- - - - - CFC CD DD
7764 I B (% of Operational nominal
current) (I B_opN=)
Measure
Master
- - - - - CFC CD DD
7765 Angle I B_remote <-> I B_local (ΦI
B=)
Measure
Master
- - - - - CFC CD DD
7766 I C (% of Operational nominal
current) (I C_opN=)
Measure
Master
- - - - - CFC CD DD
7767 Angle I C_remote <-> I C_local (ΦI
C=)
Measure
Master
- - - - - CFC CD DD
7769 V A (% of Operational nominal
voltage) (V A_opN=)
Measure
Master
- - - - - CFC CD DD
7770 Angle V A_remote <-> V A_local
(ΦV A=)
Measure
Master
- - - - - CFC CD DD
7771 V B (% of Operational nominal
voltage) (V B_opN=)
Measure
Master
- - - - - CFC CD DD
7772 Angle V B_remote <-> V B_local
(ΦV C=)
Measure
Master
- - - - - CFC CD DD
7773 V C (% of Operational nominal
voltage) (V C_opN=)
Measure
Master
- - - - - CFC CD DD
7774 Angle V C_remote <-> V C_local
(ΦV C=)
Measure
Master
- - - - - CFC CD DD
7781 Relay ID of 2nd. relay (Relay ID) Measure Slave - - - - - CFC CD DD
7782 I A (% of Operational nominal
current) (I A_opN=)
Measure Slave - - - - - CFC CD DD
7783 Angle I A_remote <-> I A_local (ΦI
A=)
Measure Slave - - - - - CFC CD DD
Functions, Settings, Information
F.5 Measured Values
SIPROTEC 4, 7SD80, Manual 397
E50417-G1100-C474-A2, Edition 02.2018
