[sc_IO240 connection PE connection, 1, en_US]
Figure 3-74
Connection of PE
²
Mount the shield cover with the delivered screws with 1.2-Nm torque. To avoid the undesired access to
the terminal connections, the screw provides a hole and the cover provides a strap for applying a seal.
