Standard for Surge Withstand
Capability (SWC)
IEEE Std C37.90.1
27
2.5 kV (peak value)
1 MHz
τ = 15 µs
400 impulses per s
Test duration ≥ 10 s
Ri = 200 Ω
Common mode and differential mode test
Standard for Fast Transient Surge
Withstand Capability
IEEE Std C37.90.1
4 kV
5 ns/50 ns
5 kHz
Burst length 15 ms
Repetition rate 300 ms
Both polarities
Ri = 50 Ω
Test duration 60 s
Common mode and differential mode test
Standard for Withstand Capability
or Relay Systems to Radiated Elec-
tromagnetic Interference from
Transceivers (Keying test)
IEEE Std C37.90.2
20 V/m
80 MHz to 1 GHz
Pulse modulation (not valid for IO216)
Damped oscillatory wave immunity
test
IEC 61000-4-18
100 kHz, 1 MHz, 2.5 kV (peak value)
3 MHz, 10 MHz, 30 MHz, 2 kV (peak value)
Test duration ≥ 60 s
Power-frequency disturbance test
at binary inputs
IEC 61000-4-16
Zone A
150 V (differential mode)
300 V (common mode)
EMC Electromagnetic Emission Tests (Type Tests, Test under Mounting Conditions)
Standards
IEC 60255-26 (product standard)
IEC 61000-6-4 (generic standard)
Conducted emission on auxiliary-voltage lines
CISPR 22
150 kHz to 30 MHz limit class A
Radiated emission CISPR 11 30 MHz to 1 000 MHz limit class A
CISPR 22 1 GHz to 6 GHz limit class A
Loading effect in electricity-supply systems, harmonics
Harmonic current emissions
Does not apply!
(see EN 61000-3-2, section 7,
power consumption < 75 W)
Loading effect in electricity-supply systems, voltage fluctuations
Flicker
Does not apply!
(see EN 61000-3-3, section 6, no
significant voltage fluctuations)
27
If a module ETH-BD-2FO is installed on a PS201 in the top slot (plug-in module position E in Figure 2-8), the immunity for this module
is restricted to 3.5 kV at the moment.
Technical Data
6.7 Electrical Tests
SIPROTEC 5, Hardware Description, Manual 237
C53000-G5040-C002-J, Edition 08.2020
