A.7 Settings
389
7SD610 Manual
C53000-G1176-C145-4
3701 Uph-e>(>) Voltage Prot. OFF
Alarm Only
ON
U>Alarm U>>Trip
OFF Operating mode Uph-e overvolt-
age prot.
3702 Uph-e> Voltage Prot. 1.0 .. 170.0 V; ∞ 85.0 V Uph-e> Pickup
3703 T Uph-e> Voltage Prot. 0.00 .. 100.00 sec; ∞ 2.00 sec T Uph-e> Time Delay
3704 Uph-e>> Voltage Prot. 1.0 .. 170.0 V; ∞ 100.0 V Uph-e>> Pickup
3705 T Uph-e>> Voltage Prot. 0.00 .. 100.00 sec; ∞ 1.00 sec T Uph-e>> Time Delay
3709A Uph-e>(>) RESET Voltage Prot. 0.30 .. 0.99 0.98 Uph-e>(>) Reset ratio
3711 Uph-ph>(>) Voltage Prot. OFF
Alarm Only
ON
U>Alarm U>>Trip
OFF Operating mode Uph-ph over-
voltage prot.
3712 Uph-ph> Voltage Prot. 2.0 .. 220.0 V; ∞ 150.0 V Uph-ph> Pickup
3713 T Uph-ph> Voltage Prot. 0.00 .. 100.00 sec; ∞ 2.00 sec T Uph-ph> Time Delay
3714 Uph-ph>> Voltage Prot. 2.0 .. 220.0 V; ∞ 175.0 V Uph-ph>> Pickup
3715 T Uph-ph>> Voltage Prot. 0.00 .. 100.00 sec; ∞ 1.00 sec T Uph-ph>> Time Delay
3719A Uphph>(>) RESET Voltage Prot. 0.30 .. 0.99 0.98 Uph-ph>(>) Reset ratio
3721 3U0>(>) (or Ux) Voltage Prot. OFF
Alarm Only
ON
U>Alarm U>>Trip
OFF Operating mode 3U0 (or Ux) ov-
ervoltage
3722 3U0> Voltage Prot. 1.0 .. 220.0 V; ∞ 30.0 V 3U0> Pickup (or Ux>)
3723 T 3U0> Voltage Prot. 0.00 .. 100.00 sec; ∞ 2.00 sec T 3U0> Time Delay (or T Ux>)
3724 3U0>> Voltage Prot. 1.0 .. 220.0 V; ∞ 50.0 V 3U0>> Pickup (or Ux>>)
3725 T 3U0>> Voltage Prot. 0.00 .. 100.00 sec; ∞ 1.00 sec T 3U0>> Time Delay (or T Ux>>)
3728A 3U0>(>) Stabil. Voltage Prot. ON
OFF
ON 3U0>(>): Stabilization 3U0-Mea-
surement
3729A 3U0>(>) RESET Voltage Prot. 0.30 .. 0.99 0.95 3U0>(>) Reset ratio (or Ux)
3731 U1>(>) Voltage Prot. OFF
Alarm Only
ON
U>Alarm U>>Trip
OFF Operating mode U1 overvoltage
prot.
3732 U1> Voltage Prot. 2.0 .. 220.0 V; ∞ 150.0 V U1> Pickup
3733 T U1> Voltage Prot. 0.00 .. 100.00 sec; ∞ 2.00 sec T U1> Time Delay
3734 U1>> Voltage Prot. 2.0 .. 220.0 V; ∞ 175.0 V U1>> Pickup
3735 T U1>> Voltage Prot. 0.00 .. 100.00 sec; ∞ 1.00 sec T U1>> Time Delay
3736 U1> Compound Voltage Prot. OFF
ON
OFF U1> with Compounding
3737 U1>> Compound Voltage Prot. OFF
ON
OFF U1>> with Compounding
3739A U1>(>) RESET Voltage Prot. 0.30 .. 0.99 0.98 U1>(>) Reset ratio
3741 U2>(>) Voltage Prot. OFF
Alarm Only
ON
U>Alarm U>>Trip
OFF Operating mode U2 overvoltage
prot.
3742 U2> Voltage Prot. 2.0 .. 220.0 V; ∞ 30.0 V U2> Pickup
3743 T U2> Voltage Prot. 0.00 .. 100.00 sec; ∞ 2.00 sec T U2> Time Delay
3744 U2>> Voltage Prot. 2.0 .. 220.0 V; ∞ 50.0 V U2>> Pickup
3745 T U2>> Voltage Prot. 0.00 .. 100.00 sec; ∞ 1.00 sec T U2>> Time Delay
3749A U2>(>) RESET Voltage Prot. 0.30 .. 0.99 0.98 U2>(>) Reset ratio
3751 Uph-e<(<) Voltage Prot. OFF
Alarm Only
ON
U<Alarm U<<Trip
OFF Operating mode Uph-e under-
voltage prot.
3752 Uph-e< Voltage Prot. 1.0 .. 100.0 V; 0 30.0 V Uph-e< Pickup
3753 T Uph-e< Voltage Prot. 0.00 .. 100.00 sec; ∞ 2.00 sec T Uph-e< Time Delay
3754 Uph-e<< Voltage Prot. 1.0 .. 100.0 V; 0 10.0 V Uph-e<< Pickup
3755 T Uph-e<< Voltage Prot. 0.00 .. 100.00 sec; ∞ 1.00 sec T Uph-e<< Time Delay
3758 CURR.SUP. Uphe< Voltage Prot. ON
OFF
ON Current supervision (Uph-e)
3759A Uph-e<(<) RESET Voltage Prot. 1.01 .. 1.20 1.05 Uph-e<(<) Reset ratio
Addr. Parameter Function C Setting Options Default Setting Comments
