A Appendix
388
7SD610 Manual
C53000-G1176-C145-4
3466 2.AR Tdead 3Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3467 2.AR Tdead1Trip Auto Reclose 0.01 .. 1800.00 sec; ∞∞sec Dead time after 1pole trip
3468 2.AR Tdead3Trip Auto Reclose 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3469 2.AR: Tdead EV. Auto Reclose 0.01 .. 1800.00 sec 1.20 sec Dead time after evolving fault
3470 2.AR: CB? CLOSE Auto Reclose YES
NO
NO CB ready interrogation before re-
closing
3471 2.AR SynRequest Auto Reclose YES
NO
NO Request for synchro-check after
3pole AR
3472 3.AR: START Auto Reclose YES
NO
NO AR start allowed in this cycle
3473 3.AR: T-ACTION Auto Reclose 0.01 .. 300.00 sec; ∞ 0.20 sec Action time
3475 3.AR Tdead 1Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3476 3.AR Tdead 2Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3477 3.AR Tdead 3Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3478 3.AR Tdead1Trip Auto Reclose 0.01 .. 1800.00 sec; ∞∞sec Dead time after 1pole trip
3479 3.AR Tdead3Trip Auto Reclose 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3480 3.AR: Tdead EV. Auto Reclose 0.01 .. 1800.00 sec 1.20 sec Dead time after evolving fault
3481 3.AR: CB? CLOSE Auto Reclose YES
NO
NO CB ready interrogation before re-
closing
3482 3.AR SynRequest Auto Reclose YES
NO
NO Request for synchro-check after
3pole AR
3483 4.AR: START Auto Reclose YES
NO
NO AR start allowed in this cycle
3484 4.AR: T-ACTION Auto Reclose 0.01 .. 300.00 sec; ∞ 0.20 sec Action time
3486 4.AR Tdead 1Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 1phase faults
3487 4.AR Tdead 2Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 1.20 sec Dead time after 2phase faults
3488 4.AR Tdead 3Flt Auto Reclose 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3phase faults
3489 4.AR Tdead1Trip Auto Reclose 0.01 .. 1800.00 sec; ∞∞sec Dead time after 1pole trip
3490 4.AR Tdead3Trip Auto Reclose 0.01 .. 1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3491 4.AR: Tdead EV. Auto Reclose 0.01 .. 1800.00 sec 1.20 sec Dead time after evolving fault
3492 4.AR: CB? CLOSE Auto Reclose YES
NO
NO CB ready interrogation before re-
closing
3493 4.AR SynRequest Auto Reclose YES
NO
NO Request for synchro-check after
3pole AR
3601 O/U FREQ. f1 Frequency Prot. ON: Alarm only
ON: with Trip
OFF
ON: Alarm only Over/Under Frequency Protec-
tion stage f1
3602 f1 PICKUP Frequency Prot. 45.50 .. 54.50 Hz 49.50 Hz f1 Pickup
3603 f1 PICKUP Frequency Prot. 55.50 .. 64.50 Hz 59.50 Hz f1 Pickup
3604 T f1 Frequency Prot. 0.00 .. 600.00 sec 60.00 sec T f1 Time Delay
3611 O/U FREQ. f2 Frequency Prot. ON: Alarm only
ON: with Trip
OFF
ON: Alarm only Over/Under Frequency Protec-
tion stage f2
3612 f2 PICKUP Frequency Prot. 45.50 .. 54.50 Hz 49.00 Hz f2 Pickup
3613 f2 PICKUP Frequency Prot. 55.50 .. 64.50 Hz 57.00 Hz f2 Pickup
3614 T f2 Frequency Prot. 0.00 .. 600.00 sec 30.00 sec T f2 Time Delay
3621 O/U FREQ. f3 Frequency Prot. ON: Alarm only
ON: with Trip
OFF
ON: Alarm only Over/Under Frequency Protec-
tion stage f3
3622 f3 PICKUP Frequency Prot. 45.50 .. 54.50 Hz 47.50 Hz f3 Pickup
3623 f3 PICKUP Frequency Prot. 55.50 .. 64.50 Hz 59.50 Hz f3 Pickup
3624 T f3 Frequency Prot. 0.00 .. 600.00 sec 3.00 sec T f3 Time Delay
3631 O/U FREQ. f4 Frequency Prot. ON: Alarm only
ON: with Trip
OFF
ON: Alarm only Over/Under Frequency Protec-
tion stage f4
3632 f4 PICKUP Frequency Prot. 45.50 .. 54.50 Hz 51.00 Hz f4 Pickup
3633 f4 PICKUP Frequency Prot. 55.50 .. 64.50 Hz 62.00 Hz f4 Pickup
3634 T f4 Frequency Prot. 0.00 .. 600.00 sec 30.00 sec T f4 Time Delay
Addr. Parameter Function C Setting Options Default Setting Comments
