6 - 11
Siemens AG ⋅ May 1998
"
A
5 1 0 7 O F F S E T S U P V
= 0 . 1 0 V
Limit value for 0 V (Offset) supervision of the analog/
digital converter in the bay units
minimum setting: V.............
maximum setting: V.............
"
A
5 1 0 8 1 5 V S U P V
= 1 . 5 0 V
Limit value for 15 V-auxiliary voltage supervision in
the bay units
minimum setting: V.............
maximum setting: V.............
"
A
5 2 0 0 S Y S T . D A T A :
S e r i a l l i n k ?
Setting for the serial interface
"
A
5 2 0 1 T E R M B A U D C U
= 1 9 2 0 0 B a u d
Baud rate for data exchange between master unit and
PC
minimum setting: Baud.........
maximum setting: Baud........
"
A
6 3 1 6 F L T R E C R E L E
= a u t o m a t i c
Refreshing the fault buffer
= automatic
Always the last fault record is stored and available for
read-out. A previously stored fault record is overwritĆ
ten
= manual
After storing two fault records, the fault recording
function remains blocked until released by operation
or binary input (>fltrec rele.). If released,
both buffers are erased irrespective of their contents.
"
A
6 3 1 7 R E L E B O S B U
= r e l e a s e d
Control facility "bay out of service"
= blocked
= released
The bay-selective control facility "bay out of service"
can be released from the master unit for all bay units
by binary input or by operation.
When set to "blocked", an attempt to take a bay out
of service locally at a bay unit will be inhibited with
the indication "NOT PERMISSIBLE".
