'(& )( )'& &) ( &!& ")& &$(( $# Ć %&( $# #)" &&#$
7 - 8
Siemens AG ⋅ May 1998
Table 7.5 Status events
Cons.
no
FNR
(HEX)
TNR
(HEX)
F1 F2 F3 Description of fault (countermeasures) plain
text inĆ
dication
1. 03 1 slave module (ZPS-BSZ or ZPS-SK) cannot be addressed
(substitution of module recommended)
yes
2. 04 102
600
1 More than one ZPS module with identical coding
(change jumper allocation or states of the switches (refer to chapter
5.2.5)
yes
3. 07 1 100 1 Overflow of the event buffer
(events are lost!)
4. 0D 601 1000 0 1 More than 24 sectionalizers configured
1001 0 1 T-TRIP-REP ( ) > T-SVS ( )
5. 0F 600 0C
10
1 Protection system failure after three unsuccessful restart attempts
(Analysis of the following buffer events)
6. 0F 600 0
0D
0E
0F
20
21
22
1 Failure on the ZPS-SBK module (replace module)
7. 0F
13
600
10D
xxyy
0
1
1
Module failure detected (requires replacement)
The affected module is marked by F1:
YY = 02; ZPS-BSZ1
03; ZPS-BSZ2
04; ZPS-BSZ3
05; ZPS-SK1
.
.
. etc
0A ZPS-SK6
8. 0F 601 1002
1004
1007
1008
Error in the station configuration
(Check the configured number of bays and isolators; check number and
location of the bus couplers and sectionalizers; verify sequence of confiĆ
guration (bus coupler before outgoing feeder before sectionalizer)
602 1004 1
2
3
4
9. 13 200 0 0 1 Module ZPS-SBK defective (replace module) yes
10. 15 10E 2
3
4
equivalent to fault no 3
(verify number of configured outgoing feeders, bus sections and bus
coupler sections)
yes
11. 15 200
600
0
2
3
2
3
4
ZPS-BSZ1 defective (replace module)
ZPS-BSZ2 defective (replace module)
ZPS-BSZ3 defective (replace module)
yes
12. 16 200
600
0
1
1
2
3
4
ZPS-SBK defective (replace module)
ZPS-BSZ1 defective (replace module)
ZPS-BSZ2 defective (replace module)
ZPS-BSZ3 defective (replace module)
yes
