Siemens AG ⋅ May 1998
PFE SAF EFE
1)
1) No battery has
to be fitted!
Table 2.1 Overview of the device connections
Variant Current connections Voltage connections FO connections
78 terminals with connection cross-sections:
max. 4 mm
2
for stranded wires
max. 7 mm
2
for solid wires
integrated FSMA plug connector
for FO connection, glass fibre
62,5/125 m
screw connection max. 4 mm
2
in parallel double leaf-spring-
crimp contact for max. 2,5 mm
2
screw connection max. 1,5 mm
2
in parallel double leaf-spring-
crimp contact for max. 1,5 mm
2
integrated FSMA plug connector
for FO connection, glass fibre
62,5/125 m
screw connection max. 1,5 mm
2
in parallel double leaf-spring-
crimp contact for max. 1,5 mm
2
integrated FSMA plug connector
for FO connection, glass fibre
62,5/125 m
