A - 3
Siemens AG ⋅ May 1998
Explanations for the following event list of the master unit (see table A.9.1):
1)
2)
3)
4)
5)
BAY
Axx
BI
OE
BSZ
FE
FNo
-SUM
C
C/G
LED
L1, L2, L3
CB
LZ
M
MW
ISOL flt
FE
FLT-No
SM
SM-No
BZ 01 ... 12
CBF
ISOi
zzz
Events can not be marshalled (rel./LED-allocation not possible)
0/1 depending on setting DA 6302/ZE
0/1 depending on setting DA 6307/ZE
0/1 depending on setting DA 6308/ZE
0/1 depending on setting DA 6312/ZE
Bay number
Bay number 01 to 48
Binary input
Operational event
ZPS-BSZ-module
Bay unit
Function No
Summation current
Coming-event
Coming/going-event
Light emitting diode
Phases
Circuit breaker
Isolator run time fault
LED indication is stored "memorized"
Measured value
Isolator fault
Fault event
Fault number
Group alarm (designates the allocation of the single alarm to the corresponding group alarm)
Group alarm No
Busbar zone 01 ... 12
Circuit breaker failure protection
Isolator i (i=1to5)
Fault-no in short text
