Page #198 background image
'(&)( )'&&)( & & !)& &$(($#   * %&($# "#)! &&#$ 


   
 
8000 CONTROL / TEST ?
8100 TEST: Auto testing ?
1)
(Input J)
8200 TEST: Manual trip ?
2)
(Input J)
8300 CONTROL: ReleasFltRecBuf ?
3)
(Input J)
8400 CONTROL: FreezeFltRecBuf ? (Input J)
8500 CONTROL: ReleasBloDifSup ? (Input J)(Release blocking by pick–up
diff current supervision ?)
8600 CONTROL: ReleasBloIsoMal ? (Input J)(Release blocking by pick–up
isolator failure (run time, status,
auxiliary voltage failure) or test
failure ?)
8700 CONTROL: Reset annun buf ?
4)
(Input J) (related to fault events
and operational events)
_______________
 Test start requires ”switched off” setting DA 6311/ZE.
 CB test possible only if bay is out of service and I–bay < I–limit value DA 6313
 If two fault record buffers are frozen, then both will be released simultaneously
 Applies for operational events and fault events
